IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card

IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card
IoT Wireless Four channel Datalogger with pulse and two-state inputs, with built-in 2G modem and Flat Rate SIM Card

IoT Wireless Datalogger kit with built-in GSM modem and Flat Rate SIM Card allows the instant connection to the COMET Cloud.

IoT Datalogger is designed to record from four binary inputs or from two pulse and two binary inputs. In case of exceeded set limits e-mail is sent from the COMET Cloud.

Alarms are also indicated locally by LED, LCD and acoustically by built-in beeper.
The recording is performed in a non-volatile electronic memory. The data can be transferred to a PC via included USB-C cable.

GSM recorder includes Traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO/IEC 17025 standard.

  • code
    U7844Msim
  • Warranty
    3 years
  • 3 410.00 AED
Add to quote

Technical data

Measured value

Two-state signal
Pulses

BINARY INPUT

Parameters of the voltage contact „L“ level input voltage:< 0,4 V(*);
„H“ level input voltage:> 2 V;
Minimum voltage applicable:0 V;
Maximum voltage applicable:+30 V DC
Parameters of the voltage-free contact Contact resistance in „switched-on“ state:< 10 kOhm;
Contact resistance in the „switched-off“ state:> 300 kOhm;
Contact voltage in the „switched-off“ state:ca 3 V;
Minimum state duration necessary for latching the state:1s

COUNTER INPUT

Counter parameters Range 24 bits (16 777 215), possibility of letting the counter overflow
Maximum pulse frequency configured for voltage input - max. 5kHz
configured for a voltage-free or open-collector transistor - max. 200Hz

GSM MODEM PARAMETERS

Quad-band 850/900/1800/1900MHz
Compliant to GSM Phase2/2+
GPRS GPRS mobile station class B
Class 4 2W @ 850/900MHz
Class 1 1W @ 1800/1900MHz

GENERAL TECHNICAL DATA

Operating temperature -20 to +60 °C
Channels 4x binary input nebo 2x binary input a 2x counter
Memory 500,000 values in noncyclic logging mode; 350,000 values in cyclic record mode
Recording interval to the internal memory adjustable from 1 second to 24 hours
Recording interval to the COMET Cloud from 5 minutes
Interval for measuring and evaluating alarms adjustable 1 s, 10 s, 1 min
Recording mode noncyclic - data logging stops after filling the memory
cyclic - after filling memory oldest data is overwritten by new
Real time clock year, leap year, month, day, hour, minute, second
Power rechargeable Li-Ion battery A8200, 3.6V/5200mAh
Protection class IP20
Dimensions 61 x 93 x 53 mm, with antenna 120 x 93 x 53 mm
Weight (including batteries) approx. 270 g
Warranty 3 years
